Cisco RV130W Wireless-N Multifunction VPN Router | RV130W-E-K9-G5

Cisco RV130W Wireless-N VPN Router, RV130W-E-K9-G5


OVERVIEW
High-performance Gigabit Ethernet ports, enabling large file transfers and multiple users
USB port for 3G/ 4G modem failover or alternative primary connectivity
IP Security (IPsec) site-to-site VPN helps enables secure connectivity for remote employees and multiple offices
Strong security: Proven stateful packet inspection (SPI) firewall and hardware encryption
Easy to set up and use s wizard-based configuration

SPECIFICATIONS
Standards
IEEE 802.11n, 802.11g, 802.11b, 802.3, 802.3u, 802.1D, 802.1p, 802.1w (Rapid Spanning Tree) 802.1X (security authentication), 802.1Q (VLAN), 802.11i (Wi-Fi Protected Access [WPA2] security), 802.11e (Bezdrôtová QoS), IPv4 (RFC 791), IPv6 (RFC 2460), Routing Information Protocol (RIP) v1 (RFC 1058), RIP v2 (RFC 1723)

Ports
LAN, WAN, USB

Switch
Power button (on/ off)

Buttons
Reset

Cabling Type
Category 5e or better

LEDs
Power, VPN, USB, WAN, Wireless, LAN (ports 1-4)

Operating System
Linux

NETWORK
Network Protocols
Dynamic Host Configuration Protocol (DHCP) server
Point-to-Point Protocol over Ethernet (PPPoE)
Point-to-Point Tunneling Protocol (PPTP)
Layer 2 Tunneling Protocol (L2TP)
DNS proxy
DHCP relay agent
IGMP proxy and multicast forwarding
Rapid Spanning Tree Protocol (RSTP)
Dynamic Domain Name System (TZO, DynDNS, 3322.org, NOIP)
Network Address Translation (NAT), Port Address Translation (PAT)
One-to-One NAT
Port management
Port mirroring
Software configurable DMZ to any LAN IP address
Session Initiation Protocol (SIP) Application Layer Gateways (ALG)

LAN
Four (4) 10/ 100/ 1000 Mbps Gigabit LAN ports s managed switch

WAN
Single (1) 10/ 100/ 1000 Mbps Gigabit WAN port

WLAN
Built-in high-speed 802.11n Bezdrôtová access point

Routing Protocols
Static routing
Dynamic routing
RIP v1 and v2
Inter-VLAN routing

Network Address Translation (NAT)
Port Address Translation (PAT), Network Address Port Translation (NAPT) protocol

VLAN Support
Port-based and 802.1Q tag-based VLANs

Number of VLANs
5 active VLANs (3-4096 range)

IPv6
Dual-stack IPv4 and IPv6
6to4 tunneling
Stateless address auto-configuration
DHCPv6 Server for IPv6 Clients on LAN
DHCP v6 client for WAN connectivity
Internet Control Message Protocol (ICMP) v6
Static IPv6 Routing
Dynamic IPv6 Routing s RIPng

Network Edge (DMZ)
Software configurable to any LAN IP address

Layer 2
802.1Q-based VLANs, 5 active VLANs

SECURITY
Firewall
Stateful packet inspection (SPI) firewall, port forwarding and triggering, denial-of-service (DoS) prevention, software-based DMZ
DoS Attacks Prevented:
SYN Flood Detect Rate
Echo Storm
ICMP Flood
UDP Flood
TCP Flood
Block Java, Cookies, Active-X, HTTP Proxy

Access Control
IP access control lists; MAC-based Bezdrôtová access control

Content Filtering
Static URL blocking or keyword blocking

Secure Management
HTTPS, username/ password complexity

WPS
Wi-Fi Protected Setup

User Privileges
2 levels of access: admin and guest

VPN
Gateway-to-gateway IPsec VPN
10 gateway-to-gateway IPSec tunnels

Client-to-gateway IPsec VPN
10 client-to-gateway IPsec tunnels using TheGreenBow and ShrewSoft VPN client

PPTP VPN
10 PPTP tunnels for remote client access

Encryption
Triple Data Encryption Standard (3DES)

Authentication
MD5/ SHA1

VPN Pass-through
IPsec/ PPTP/ Layer 2 Tunneling Protocol (L2TP) pass-through

QUALITY OF SERVICE
QoS
802.1p port-based priority on LAN port, application-based priority on WAN port
3 queues
Differentiated Services Code Point support (DSCP)
Class of Service (CoS)
Bandwidth Management for service prioritization

Jumbo Frame
Supports Jumbo Frame on Gigabit ports - at least 1536B

PERFORMANCE
NAT Throughput
800 Mbps

Concurrent Sessions
12, 000

IPsec VPN Throughput (3DES/ AES)
50 Mbps

CONFIGURATION
Web User Interface
Simple, browser-based configuration (HTTP/ HTTPS)

MANAGEMENT
Management Protocols
Web browser, Simple Network Management Protocol (SNMP) v3, Bonjour, Universal Plug and Play (UPnP)

Event Logging
Local, syslog, email alerts

Network Diagnostics
Ping, Traceroute, and DNS Lookup

Upgradability
Firmware upgradable through web browser, imported/ exported configuration file

System Time
Supports NTP, Day Light Savings, Manual entry

Languages
GUI supports English, French, Italian, German, and Spanish

WIRELESS
Radio and modulation type
802.11b: direct sequence spread spectrum (DSSS), 802.11g: orthogonal frequency division multiplexing (OFDM), 802.11n: OFDM

WLAN
2.4GHz IEEE 802.11n standard-based access point s 802.11b/ g compatibility

Operating channels
11 North America, 13 most of Europe, auto channels selection

Wireless isolation
Wireless isolation between clients

External antennas
2 fixed antennas

Antenna gain in dBi
2 dBi

Transmit power
802.11b: 16.5 dBm +/ - 1.5 dBm; 802.11g: 15 dBm +/ - 1.5 dBm; 802.11n: 12.5 dBm +/ - 1.5 dBm

Receiver sensitivity
* -87 dBm at 11 Mbps, -71 dBm at 54 Mbps, -68 dBm at mcs15, HT20, -66 dBm at mcs15, HT40

Radio Frequency
Single-band, works on 2.4GHz

Wireless Domain Service (WDS)
Allows Bezdrôtová signals to be repeated by až do 4 compatible devices

Operating Modes
Multifunction device-Bezdrôtová router, access point mode s WDS, Point-to-Point Bridge mode s WDS, Point-Multi Point Bridge mode s WDS, Repeater mode s WDS

Active WLAN clients
Support až do 64 concurrent clients in Bezdrôtová router mode and Bezdrôtová Access Point mode

Multiple SSIDs
Supports multiple Service Set Identifiers (SSIDs), až do 4 separate virtual networks

Wireless VLAN map
Supports SSID to VLAN mapping s Bezdrôtová client isolation

WLAN security
Wired Equivalent Privacy (WEP), WPA, WPA2-PSK, WPA2-ENT, 802.11i

Wi-Fi Multimedia (WMM)
WMM, WMM power save (WMM-PS)

ENVIRONMENTAL
Power
12V 2A

Certifications
FCC class B, CE, IC, Wi-Fi

Operating temperature
0& deg; to 40& deg;C (32& deg; to 104& deg;F)

Storage temperature
* -20& deg; to 70& deg;C (-4& deg; to 158& deg;F)

Operating humidity
10 to 85 percent noncondensing
