UBIQUITI NanoBeam M5, 5GHz, 16dBi, 802.11n MIMO 2x2 TDMA, PoE (nastup. LOCO M5) | NBE-M5-16

UBIQUITI NanoBeam M5, 5GHz, 16dBi, 802.11n MIMO 2x2 TDMA, PoE (nastup. LOCO M5)


Model NBE-M5-19 NBE-M5-16
Processor Specs Atheros MIPS 74Kc, 560 MHz
Memory 64 MB DDR2, 8 MB Flash
Networking Interface (1) 10/ 100 Ethernet Port
Wireless Approvals FCC, IC, CE
RoHS Compliance Yes
Model NBE-M5-19 NBE-M5-16
Rozmery
140 x 140 x 54 mm
(5.51 x 5.51 x 2.13 in)
Weight
0.320 kg
(0.71 lb)
Power Supply 24V, 0.5A PoE
Power Method
Passive PoE
(Pairs 4, 5+; 7, 8 Return)
Max. Power Consumption 6W
Gain 16 dBi
Wind Loading 21.4 N @ 200 km/ h (4.8 lbf @ 125 mph)
Wind Survivability 200 km/ h (125 mph)
LEDs (1) Power, (1) LAN, (4) WLAN
Signal Strength LEDs Software-Adjustable to Correspond to Custom RSSI Levels
Channel Sizes 5/ 8/ 10/ 20/ 30/ 40 MHz
Polarization Dual Linear
Enclosure Outdoor UV Stabilized Plastic
Mounting Pole-Mount (Kit Included), Wall-Mount
ESD/ EMP Protection Air: ± 24 kV, Contact: ± 24 kV
Operating Temperature -40 to 70° C (-40 to 158° F)
Operating Humidity 5 to 95% Noncondensing
Salt Fog Test IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5
Vibration Test IEC 68-2-6
Temperature Shock Test IEC 68-2-14
UV Test IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
Wind-Driven Rain Test ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
Operating Frequency

Operating Frequency Worldwide: 5170 - 5875 MHzUSA: 5725 - 5850 MHz
