ZyXEL 24xGb 4xRJ45 / SFP 2xSFP L2+ switch GS2210-24 | GS2210-24-EU0101F

28-port Managed Layer2+ Gigabit Ethernet switch, 24x Gigabit metal + 4x Gigabit dual personality (RJ45/ open SFP), L2 multicast, IGMP snooping, MVR, IP source guard, DHCP snooping, ARP inspection, CPU protection, IPv6, 802.3az (Green)


OVERVIEW
Fully managed Layer 2 switching solution
GbE RJ-45 and GbE SFP connectivity
L2 multicast, IGMP snooping, MVR and voice VLAN for convergence
Enhanced network protection s IP source guard, DHCP snooping, ARP inspection, CPU protection
L2, L3 and L4 filtering, MAC freeze, port isolation, guest VLAN for improved isolation and access control
Future-proofed s IPv6 support
Supports ZON Utility and ZyXEL One Network inter-device features for easier, more efficient setup and management

SPECIFICATIONS
SWITCH CLASS
Switch class
Layer 2

PORT DENSITY
100/ 1000 Mbps
24

Dual-personality Gigabit (SFP/ RJ-45)
4

PERFORMANCE
Switching capacity (Gbps)
56

Forwarding rate (Mpps)
41.67

Packet buffer (byte)
1.5 M

MAC address table
16 K

IP address table
* -

Routing entries
* -

Routing domains
* -

MANAGEMENT
IPv6 management
Yes

CLI, web GUI
Yes

iSTACKING (single IP management)
Yes

Out-of-bound management port
* -

ROUTING/ REDUNDANCY
OSPF
* -

RIP v1, v2
* -

Static IP routing
* -

VRRP
* -

Spanning tree (STP/ MSTP/ RSTP)
Yes/ Yes/ Yes

Redundant power support
* -

QUALITY OF SERVICE
Priority queues
8

Data prioritization (SPQ/ WRR/ WFQ )
Yes/ Yes/ Yes

Guest VLAN
Yes

IGMP snooping (v1/ v2/ v3)
Yes

MVR
Yes

Jumbo frame (byte)
Yes

DVMRP
* -

802.1p CoS
Yes

SECURITY
MAC freeze/ Intrusion lock
Yes

802.1X authentication
Yes

TACACS+/ RADIUS
Yes

ACL security filter L2/ L3/ L4
Yes

sFlow
* -

CPU protection
Yes

POWER
Input
100 - 240 V AC, 50/ 60 Hz

Max. power consumption (watt)
27.2

Total PoE power budget (watt)
* -

Removable power module
* -

GREEN FEATURES
Fanless
Yes

IEEE Energy-Efficient-Ethernet
Yes

ENVIRONMENTAL SPECIFICATION
Operating temperature
0& deg;C to 50& deg;C

Storage temperature
* -40& deg;C to 70& deg;C

Operating humidity
10% to 95% (non-condensing)

Storage humidity
10% to 90% (non-condensing)

MTBF (hr)
211, 623

Heat dissipation (BTU/ hr)
92.75

Rozmery (WxDxH)
441 x 131 x 44 mm

Weight
2.62 kg

Removable fan module
* -
