TrippLite PowerVerter® APS X Series 6000W Inverter / Charger with Auto-Transfer Switching | APSX6048VRNET

OWERVERTER® Series

APSX6048VRNET
PowerVerter® APS X Series 6000W Inverter/ Charger with Auto-Transfer Switching and Line Interactive Voltage Regulation
48V DC or 208/ 230V (selectable) AC input; 208/ 230V, 50/ 60 Hz, pure sine wave output (hardwired)
6000 watts continuous, 9000 watts OverPower and 12000 watts DoubleBoost inverter output
3-stage, 23/ 90 amp selectable wet/ dry cell battery charger; Auto Transfer Switching; Automatic Voltage Regulation
DB9 communication port for SNMPWEBSOLOHV management.
Excellent for alternative power and standby power needs.


SpecificationsOVERVIEW
Intended Application Emergency Power, Remote Power, Alternative Power
OUTPUT
Frequency compatibility 50 / 60 Hz
Output watts 6000
Continuous output capacity (watts) 6000
Peak output capacity (watts) 12000
Output nominal voltage 208/ 230V
Output voltage regulation LINE POWER (AC): Maintains 208/ 230V nominal sine wave output from line power source. INVERTER POWER (AC): Maintains sine wave output voltage of 208/ 230 VAC (+/ -5%).
Output frequency regulation 50/ 60 Hz (+/ - 0.3 Hz)
Outlet quantity / type Hardwire
INPUT
Nominal Input Voltage(s) Supported 208V AC; 230V AC
Recommended Electrical Service DC INPUT: Requires 48VDC input source capable of delivering 138A for the required duration (when used at full continuous capacity - DC requirements increase during OverPower and DoubleBoost operation). For automotive applications, professional hardwire installation with 250A minimum battery system fusing is recommended.
Maximum input amps / watts DC INPUT: Full continuous load - 145A at 48VDC. AC INPUT: 30 amps at 208/ 230VAC with full inverter and charger load
Input connection type DC INPUT: Set of DC bolt-down terminals. AC INPUT: Hardwire via built in terminal strip with cover plate
Voltage compatibility (VAC) 208; 230
Voltage compatibility (VDC) 48
BATTERY
Expandable battery runtime Runtime is expandable with any number of user supplied wet or gel type batteries
DC system voltage (VDC) 48
Battery Pack Accessory (optional) 98-121 sealed lead acid battery (optional)
Battery charge Selectable 23 / 90 amp
VOLTAGE REGULATION
Voltage regulation description Includes automatic voltage regulation to correct brownouts and over-voltages back to usable levels
Overvoltage correction Over-voltages are automatically reduced by 10%
Brownout correction Brownouts are automatically boosted by 10% and 20%
LEDS ALARMS & SWITCHES
Switches 3 position on/ off/ remote switch enables simple on/ off power control plus "auto/ remote" setting that enables distant on/ off control of the inverter system when used in conjunction with optional APSRM4 accessory when used in inverter mode. In AC uninterruptible power mode, auto/ remote setting enables automatic transfer from line power to battery power - to maintain continuous AC power to connected loads.
Front panel LEDs Set of 6 LEDs offer continuous status information on load percentage (6 levels reported) and battery charge level (7 levels reported). See manual for sequences.
PHYSICAL
Shipping Dimensions (HWD/ in) 17.13 x 23.82 x 14.17
Shipping Dimensions (HWD/ cm) 43.51 x 60.5 x 36
Shipping weight (lbs) 125
Shipping weight (kg) 56.25
Unit Dimensions (HWD/ in) 10 x 19.5 x 9
Unit Dimensions (HWD/ cm) 25.5 x 49.5 x 22.71
Unit weight (lbs) 106
Unit weight (kg) 47.7
Cooling method Dual multi-speed fan
Material of construction Metal
Style Heavy-duty with built-in battery charger
ENVIRONMENTAL
Relative Humidity 0-95% non-condensing
LINE / BATTERY TRANSFER
Transfer time from line power to battery mode Dip-switch selectable 20 millisecond (full cycle) / 10 millisecond (half-cycle) transfer times which are compatible with many computers, servers and networking equipment - verify transfer time compatibility of loads for UPS applications
Low voltage transfer to battery power In 230V AC "auto" mode, inverter/ charger switches to battery mode as line voltage drops to 170V AC (user adjustable to 180V). In 208V AC "auto" mode, inverter/ charger switches to battery mode as line voltage drops to 165V (user adjustable to 175V)-see manual
High voltage transfer to battery power In 230V AC "auto" mode, inverter/ charger switches to battery mode as line voltage increases to 260V (user adjustable to 270 - see manual), In 208V AC "auto" mode, inverter/ charger switches to battery mode as line voltage increases to 235V (user adjustable to 245V-see manual)
SPECIAL FEATURES
Appearance Black color
Load Sensing Optional load sense function enables automatic inverter shutoff and startup as connected equipment is powered off and on. Front panel load sense potentiometer can be set to shutoff or turn on inverter power in response to loads of any level, up to 150 watts.
Remote control capability Yes
TVSS grounding Main grounding lug connects inverter/ charger to earth or vehicle chassis ground
CERTIFICATIONS
Certifications RoHS compliant
WARRANTY
Product Warranty Period (Worldwide) 2-year limited warranty
